Artikelcode: SX3032F
Netwerk - Switches - Beheerd
Geschatte levertermijn:
27-09-2026 Contacteer ons
Magazijn: tabr
| Poorten & interfaces | |
|---|---|
| Aantal basis-switching RJ-45 Ethernet-poorten: | 1 |
| Aantal geïnstalleerde SFP+ modules: | 32 |
| Console port: | RJ-45/Micro-USB |
| Gewicht en omvang | |
| Breedte: | 440 mm |
| Diepte: | 330 mm |
| Hoogte: | 44 mm |
| Energie | |
| Stroombron: | AC |
| Vermogenstoevoer inclusief: | Ja |
| AC-ingangsspanning: | 100 - 240 V |
| AC-ingangsfrequentie: | 50/60 Hz |
| Vermogensverbruik (max): | 49,4 W |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T): | -5 - 45 °C |
| Temperatuur bij opslag: | 40 - 70 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 10 - 90 procent |
| Luchtvochtigheid bij opslag: | 5 - 90 procent |
| Protocollen | |
| GARP VLAN Registratieprotocol (GVRP): | Ja |
| IPv4- & IPv6-functies: | Dual stack IPv4/IPv6, ICMPv6, IPv6 TFTP |
| IP Source Guard (IPSG): | Ja |
| Netwerk | |
| Netwerkstandaard: | IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ah, IEEE 802.3x |
| Port mirroring: | Ja |
| Datastroombeheer: | Ja |
| Verbindingsaggregatie: | Ja |
| Broadcast stormbeheer: | Ja |
| Rate limiting: | Ja |
| Spanning tree protocol: | Ja |
| IPv4-routes: | 48 |
| IPv6-routes: | 48 |
| VLAN=ondersteuning: | Ja |
| Virtuele LAN-functies: | Protocol-based VLAN, SSID-based VLAN assignment, Tagged VLAN, VLAN mapping, Voice VLAN |
| Aantal VLANs: | 30 |
| Data-uitwisseling | |
| MAC-adrestabel: | 32000 entries |
| Switchingcapaciteit: | 640 Gbit/s |
| Verzending snelheid: | 240 Mpps |
| Aantal wachtrijen: | 8 |
| Statische route: | Ja |
| Aantal statische routes: | 128 |
| Aantal IP-interfaces: | 128 |
| Jumbo Frames ondersteuning: | Ja |
| Jumbo frames: | 9 |
| Packet buffergeheugen: | 24 MB |
| Beveiliging | |
| DHCP-functies: | DHCP relay, DHCP server, DHCPv6 snooping |
| Access Control List (ACL): | Ja |
| IGMP snooping: | Ja |
| Statische poort beveiliging: | Ja |
| SSH/SSL support: | Ja |
| Bescherming lus: | Ja |
| IP-MAC-Port binding: | Ja |
| Authenticatie: | MAC-gebaseerde authenticatie, Poortgebaseerde authenticatie |
| Wachtwoordbeveiliging: | Ja |
| Authenticatie type: | AAA, TACACS+ |
| Algoritmen wachtrijplanning: | Priority queuing (PQ), SP, Weighted Round Robin (WRR) |
| Certificaten | |
| Certificaten van naleving: | CE, Federal Communications Commission (FCC), RoHS |
| Beheerfuncties | |
| Switch type: | Managed |
| Switch-laag: | L2+ |
| Quality of Service (QoS): | Ja |
| Cloud-beheerd: | Ja |
| ARP-inspectie: | Ja |
| Locatie-instellingen (CLI) configureren: | Ja |
| MIB-ondersteuning: | • MIB II (RFC1213) • Interface MIB (RFC2233) • Ethernet Interface MIB (RFC1643) • Bridge MIB (RFC1493) • P/Q-Bridge MIB (RFC2674) • RMON MIB (RFC2819) • RMON2 MIB (RFC2021) • Radius Accounting Client MIB (RFC2620) • Radius Authentication Client MIB (RFC2618) • Remote Ping, Traceroute MIB (RFC2925) • Support TP-Link private MIB |
| Inhoud van de verpakking | |
| Meegeleverde kabels: | Stroom |
| Snelstartgids: | Ja |
| Design | |
| Rack-montage: | Ja |
| Kleur van het product: | Zwart |
| Overtollige fans ondersteuning: | Ja |
| Aantal ventilatoren: | 2 ventilator(en) |
| Multicast-functies | |
| Multicast-ondersteuning: | Ja |
| Aantal gefilterde multicast-groepen: | 4000 |
| Multicast Listener Discovery (MLD) snooping: | Yes |
