Artikelcode: SRTL5KRM2UI-HW
Netwerk - Noodstroom - UPS
Onbekend levertermijn Contacteer ons
Magazijn: tabr
| Gewicht en omvang | |
|---|---|
| Breedte: | 432 mm |
| Diepte: | 701 mm |
| Hoogte: | 86 mm |
| Gewicht: | 29,2 kg |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T): | 0 - 40 °C |
| Temperatuur bij opslag: | -15 - 45 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 0 - 95 procent |
| Luchtvochtigheid bij opslag: | 0 - 95 procent |
| Hoogte, in bedrijf: | 0 - 3048 m |
| Hoogte bij opslag: | 0 - 15240 m |
| Verpakking | |
| Breedte verpakking: | 585 mm |
| Diepte verpakking: | 984 mm |
| Hoogte verpakking: | 392 mm |
| Gewicht verpakking: | 38,5 kg |
| Certificaten | |
| Certificaten van naleving: | CE, UKCA |
| Accu/Batterij | |
| Batterijtechnologie: | Lithium-Ion (Li-Ion) |
| Accu/Batterij voltage: | 180 V |
| Design | |
| Vormfactor: | Rackmontage |
| Kleur van het product: | Grijs |
| Rackcapaciteit: | 2U |
| Internationale veiligheidscode (IP): | IP20 |
| Kenmerken | |
| UPS-topologie: | Dubbele conversie (online) |
| Output power capacity: | 5 kVA |
| Uitgangsvermogen: | 5000 W |
| Golfvorm: | Sinus |
| Ingang operation voltage (min): | 180 V |
| Ingang operation voltage (max): | 275 V |
| Frequentie: | 40 - 70 Hz |
| Uitgang operation voltage (max): | 220 V |
| Warmtedissipatie: | 931 BTU/h |
| Geluidsniveau: | 55 dB |
| Logistieke gegevens | |
| Garantieperiode: | 5 jaar |
