| Processor | |
|---|---|
| Processorfamilie: | Intel Celeron J |
| Processorfabrikant: | Intel |
| Processormodel: | J6412 |
| Frequentie van processor: | 2 GHz |
| Aantal processorkernen: | 4 |
| Processor aantal threads: | 4 |
| Maximale turbofrequentie van processor: | 2,6 GHz |
| Processor cache: | 1,5 MB |
| Processor cache type: | L2 |
| Aantal geïnstalleerde processoren: | 1 |
| Geheugen | |
| Intern geheugen: | 8 GB |
| Maximum intern geheugen: | 32 GB |
| Intern geheugentype: | DDR4-SDRAM |
| Geheugenslots: | 2x SO-DIMM |
| Kloksnelheid geheugen: | 3200 MHz |
| Beeldscherm | |
| Inclusief monitor: | Nee |
| Poorten & interfaces | |
| Aantal USB 2.0-poorten: | 1 |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A: | 0 |
| Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C: | 0 |
| Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A: | 2 |
| Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C: | 0 |
| Aantal Thunderbolt 3-poorten: | 0 |
| Aantal HDMI-poorten: | 1 |
| HDMI versie: | 2.0b |
| Aantal Ethernet LAN (RJ-45)-poorten: | 2 |
| Aansluiting voor netstroomadapter: | Ja |
| Seriële poort(en): | 1 |
| Gewicht en omvang | |
| Breedte: | 120 mm |
| Diepte: | 75 mm |
| Hoogte: | 51 mm |
| Gewicht: | 720 g |
| Gewicht verpakking: | 1,2 kg |
| Energie | |
| Netvoeding: | 90 W |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T): | 0 - 40 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 20 - 80 procent |
| Netwerk | |
| Ethernet LAN: | Ja |
| Wifi: | Nee |
| Ethernet LAN, data-overdrachtsnelheden: | 100,1000,2500 Mbit/s |
| LAN controller: | Intel I226-V |
| Opslagmedia | |
| Totale opslagcapaciteit: | 120 GB |
| Soort optische drive: | Nee |
| Opslagmedia: | SSD |
| Aantal storage drives geïnstalleerd: | 1 |
| Totale capaciteit SSD's: | 120 GB |
| Aantal geïnstalleerde SSD's: | 1 |
| SSD capaciteit: | 120 GB |
| SSD interfaces: | SATA |
| SSD-vormfactor: | M.2 |
| M.2 SSD-grootte: | 2242 (22 x 42 mm) |
| Certificaten | |
| Certificaten van naleving: | BSMI, CB, CE, Federal Communications Commission (FCC), VCCI, cTUVus |
| Software | |
| Inclusief besturingssysteem: | Nee |
| Inhoud van de verpakking | |
| Inclusief VESA-montage: | Ja |
| Overige specificaties | |
| Fanloos: | Ja |
| Design | |
| Type behuizing: | Mini PC |
| Kleur van het product: | Zwart, Blauw |
| Volume: | 0,46 l |
| Ondersteuning voor plaatsing: | Horizontaal/Verticaal |
| VESA-montage: | Ja |
| Materiaal behuizing: | Aluminium |
| Grafisch | |
| Aparte grafische adapter: | Nee |
| Ingebouwde grafische adapter: | Ja |
| Discreet grafische adapter model: | Niet beschikbaar |
| On-board graphics adapter model: | Intel UHD Graphics |
| Interne-GPU-fabrikant: | Intel |
| Familie ingebouwde grafische adapter: | Intel UHD Graphics |
| Prestatie | |
| Type product: | Mini PC |
| Wachtwoordbeveiliging: | Ja |
| Trusted Platform Module (TPM): | Ja |
| Trusted Platform Module (TPM) version: | 2.0 |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS): | 84714900 |
