Artikelcode: SG2428LP
Netwerk - Switches - Beheerd
Geschatte levertermijn:
26-09-2026 Contacteer ons
Magazijn: tabr
| Poorten & interfaces | |
|---|---|
| Aantal basis-switching RJ-45 Ethernet-poorten: | 24 |
| Type basis-switching RJ-45 Ethernet-poorten: | Gigabit Ethernet (10/100/1000) |
| Aantal moduleslots SPF: | 4 |
| Gewicht en omvang | |
| Breedte: | 440 mm |
| Diepte: | 220 mm |
| Hoogte: | 44 mm |
| Energie | |
| Stroombron: | AC/PoE |
| AC-ingangsspanning: | 100 - 240 V |
| AC-ingangsfrequentie: | 50/60 Hz |
| Vermogensverbruik (max): | 184,7 W |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T): | 0 - 40 °C |
| Temperatuur bij opslag: | -40 - 70 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 10 - 90 procent |
| Luchtvochtigheid bij opslag: | 5 - 90 procent |
| Warmtedissipatie: | 628 BTU/h |
| Netwerk | |
| Netwerkstandaard: | IEEE 802.3af, IEEE 802.3at |
| 10G support: | Nee |
| Datastroombeheer: | Ja |
| Verbindingsaggregatie: | Ja |
| Spanning tree protocol: | Ja |
| Auto-negotiation: | Ja |
| VLAN=ondersteuning: | Ja |
| Virtuele LAN-functies: | MAC address-based VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN |
| Aantal VLANs: | 4000 |
| Data-uitwisseling | |
| MAC-adrestabel: | 8000 entries |
| Switchingcapaciteit: | 56 Gbit/s |
| Verzending snelheid: | 41,66 Mpps |
| Jumbo Frames ondersteuning: | Ja |
| Packet buffergeheugen: | 4,1 MB |
| Beveiliging | |
| DHCP-functies: | DHCP relay, DHCP server |
| Access Control List (ACL): | Ja |
| IGMP snooping: | Ja |
| Beheerfuncties | |
| Switch type: | Managed |
| Switch-laag: | L2/L2+ |
| Quality of Service (QoS): | Ja |
| Web-gebaseerd management: | Ja |
| Cloud-beheerd: | Ja |
| ARP-inspectie: | Ja |
| Design | |
| Rack-montage: | Ja |
| Kleur van het product: | Grijs |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE): | Ja |
| Aantal Power over Ethernet plus (PoE +)-poorten: | 16 |
| Vermogen per poort Power over Ethernet (PoE): | 30 W |
| Totaal Power over Ethernet (PoE)-budget: | 150 W |
| Prestatie | |
| Fanloos: | Ja |
| Multicast-functies | |
| Multicast-ondersteuning: | Ja |
