Artikelcode: GVSUPS30KHS
Netwerk - Noodstroom - UPS
Onbekend levertermijn Contacteer ons
Magazijn: tabr
| Technische details | |
|---|---|
| Duurzaamheidscertificaten: | RoHS |
| Code geharmoniseerd systeem (HS): | 85078000 |
| Gewicht en omvang | |
| Breedte: | 521 mm |
| Diepte: | 847 mm |
| Hoogte: | 1485 mm |
| Gewicht: | 210 kg |
| Breedte verpakking: | 640 mm |
| Diepte verpakking: | 990 mm |
| Hoogte verpakking: | 1680 mm |
| Gewicht verpakking: | 235 kg |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T): | 0 - 40 °C |
| Temperatuur bij opslag: | -25 - 55 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 0 - 95 procent |
| Luchtvochtigheid bij opslag: | 10 - 80 procent |
| Design | |
| Vormfactor: | Tower |
| Kleur van het product: | Wit |
| Type beeldscherm: | LCD |
| LED-indicatoren: | Ja |
| Internationale veiligheidscode (IP): | IP21 |
| Certificering: | CSA C22.2 NO. 107.3, EN/IEC 62040-1, EN/IEC 62040-2, EN/IEC 62040-3, FCC Part 15 Class A, IEC 60721-4-2 Level 2M2, UL 1778 5th edition |
| Kenmerken | |
| UPS-topologie: | Dubbele conversie (online) |
| Output power capacity: | 30 kVA |
| Uitgangsvermogen: | 30000 W |
| Golfvorm: | Sinus |
| Ingang operation voltage (min): | 340 V |
| Ingang operation voltage (max): | 460 V |
| Frequentie: | 40/70 Hz |
| Uitgang operation voltage (min): | 380 V |
| Uitgang operation voltage (max): | 415 V |
| Output frequentie: | 50/60 Hz |
| Stroom (max.): | 56 A |
| Aantal input fases: | 3 |
| Aantal output fases: | 3 |
| Efficientie: | 96,8 procent |
| Input vermogensfactor: | 0,99 |
| Crest factor: | 2.5:1 |
| ECO mode: | Ja |
| Output voltage THD: | 3 procent |
| Geluidsniveau: | 65 dB |
| Geluidsalarm(en): | Ja |
