Design
Cooling type > Active
Fan diameter > 12 cm
Fan location > Top
Number of fans > 1 ventilator(en)
On/off switch > Yes
Product colour > Black
Package dimensions
Gross Weight (Package, kg) > 0,65 kg
Performance
80 PLUS certification > 80 PLUS Bronze
ATX version > 2.31
Bearing technology > HDB
Mean time between failures (MTBF) > 100000 Hour
Noise level > 39 dB
Power supply unit (PSU) form factor > ATX
Purpose > PC
Ports & interfaces
ATX power connector (20+4 pin) > Yes
Cabling type > Non-Modular
CPU P4 connector (4-pin) > 1
CPU power cable length > 60 cm
CPU power connector (4+4 pin) > Yes
Floppy disk drive connector > Yes
Motherboard power cable length > 50 cm
Motherboard power connector > 20+4 pin ATX
Number of SATA power connectors > 6
PCI Express power cable length > 65 cm
PCI Express power connectors (6+2 pin) > 4
Peripheral (Molex) power cable length > 150, 500
Peripheral (Molex) power connectors (4-pin) > 3
SATA power cable length > 150, 500
Power
AC input voltage > 100 - 240 V
Combined power (-12V) > 3,6 Watt
Combined power (+12V) > 650 Watt
Combined power (+3.3V) > 120 Watt
Combined power (+5V) > 650 Watt
Combined power (+5Vsb) > 12,5 Watt
Input current > 12 - 6 A
Max output current (-12V) > 0,3 A
Max output current (+12V) > 54,17 A
Max output current (+3.3V) > 20 A
Max output current (+5V) > 20 A
Max output current (+5Vsb) > 20 A
Maximum input current (@110V) > 12 A
Maximum input current (@220V) > 6 A
Power Factor Correction (PFC) type > Active
Power protection features > Over power, Overcharge, Short circuit, Under voltage
Total power > 650 Watt
Product dimensions
Net Weight (Product, kg) > 0,5 kg
Vendor information
Brand Name > Gigabyte
Warranty > 1 Ja(a)r(en)
