Artikelcode: CPE710
Netwerk - Acces Points - 2.4/5 Ghz
Onbekend levertermijn Contacteer ons
Magazijn: pcwv
5GHz 867Mbps, 27dBm, 2x2 MIMO, 802.3a/n/ac, 23dBi, IP65
TP-LINK CPE710, 867 Mbit/s, 10,100,1000 Mbit/s, 5.15 - 5.85 GHz, IEEE 802.11a,IEEE 802.11ac,IEEE 802.11n, 80 MHz, 27 dBmW
Blazing Speed without Wait 256 QAM and an 80 MHz bandwidth boosts overall speeds up to 867 Mbps, 3Ã faster than 802.11n Wi-Fi.
Professional-Standard 23 dBi Directional
Antenna for Long-range Wireless Transmission With 23 dBi high-gain directional Cassegrain antenna and dedicated metal reflector, the CPE710 provides excellent beam directivity, improved latency, and noise immunity. Professional performance, coupled with user-friendly design, makes the 5 GHz 867 Mbps 23 dBi Outdoor CPE710 an ideal choice and cost-effective solution for outdoor long-distance wireless networking applications.
Compact and Lightweight Packaging Small and lightweight boxes benefit shipping, logistics, and retail.
Pharos Control â Centralized Management System CPE710 comes equipped with Pharos Control centralized management software, helping users easily manage all devices in their network from a single PC. Functions include device discovery, status monitoring, firmware upgrading, and network maintenance. An intuitive web-based interfaceâ PharOS - provides an alternative management method and allows professionals to access more detailed configurations.
| Antenne | |
|---|---|
| Antenne versterkingsniveau (max) | 23 dBi |
| Beheerfuncties | |
| Syslog | Ja |
| Web-gebaseerd management | Ja |
| Beveiliging | |
| IGMP snooping | Ja |
| Ondersteunde beveiligingsalgoritmen | HTTPS, SNMP, SSH, WPA, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP |
| MAC adres filtering | Ja |
| Auto Wireless Distribution System (WDS) | Ja |
| Service Set Identifier (SSID) functies | Multiple SSIDs, SSID-broadcast, SSID-broadcast aan/uit |
| Design | |
| Reset button | Ja |
| Plaatsing | Paal |
| LED-indicatoren | Stroom |
| Certificering | CE, FCC, RoHS, IC |
| Materiaal behuizing | Kunststof |
| Kleur van het product | Wit |
| Internationale veiligheidscode (IP) | IP65 |
| Eisen aan de omgeving | |
| Temperatuur, in bedrijf | -40 - 70 ðC |
| Temperatuur bij opslag | -40 - 70 ðC |
| Luchtvochtigheid bij opslag | 5 - 95 procent |
| Relatieve luchtvochtigheid, in bedrijf | 10 - 90 procent |
| Energie | |
| Power over Ethernet (PoE) | Ja |
| Frequentie | 50/60 Hz |
| Ingangsspanning | 100 - 240 V |
| Spanning | 24 V |
| Output current | 0.6 A |
| Gewicht en omvang | |
| Diepte | 280 mm |
| Breedte | 366 mm |
| Hoogte | 207 mm |
| Kenmerken | |
| Maximale overdrachtssnelheid van gegevens | 867 Mbit/s |
| Netwerkstandaard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n |
| Ethernet LAN, data-overdrachtsnelheden | 10, 100, 1000 Mbit/s |
| Frequentieband | 5.15 - 5.85 GHz |
| Automatische kanaalselectie | Ja |
| Kanaalbandbreedte | 80 MHz |
| Zendvermogen | 27 dBmW |
| 2,4 GHz | Nee |
| 5 GHz | Ja |
| Draadloze isolatie | Ja |
| MIMO | Ja |
| Dynamic Frequency Selection (DFS) | Ja |
| Poorten & interfaces | |
| Aantal Ethernet LAN (RJ-45)-poorten | 1 |
| Prestatie | |
| Compatibele besturingssystemen | Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX, Linux |
| Type processor | Ja |
| Frequentie van processor | 750 MHz |
| Intern geheugen | 128 MB |
| Flash memory | 16 MB |
| Protocollen | |
| Universal Plug and Play ( UPnP ) | Ja |
| Verpakking | |
| Meegeleverde kabels | AC |
| Type verpakking | Doos |
| Snelstartgids | Ja |
| Inclusief PoE-adapter | Ja |
| MPN & EAN | |
| EAN | 0845973089702, 6935364089702 |
| MPN | CPE710 |
