The re-invention of the most relied upon desktop UPS in history: the Back-UPS!
The Back-UPS CS provides professional-grade power protection for office and home office systems. Battery powered & surge protected power outlets, built-in phone/fax/modem line (DSL compatible) protection, safe system shutdown software with sophisticated power management features and pro-active audio-visual status indicators ensure office systems and their valuable data are protected from dangerous power sur... Lees de volledige beschrijving
Battery
Automatic battery test > Yes
Battery capacity > 7 Ah
Battery capacity > 116 VAh
Battery life (max) > 6 jaar
Battery recharge time > 6 Hour
Battery technology > Sealed Lead Acid (VRLA)
Battery voltage > 12 V
Typical backup time at full load > 8,6 min
Typical backup time at half load > 22,1 min
Design
Cable length > 1,83 m
Certification > C-tick, CE, EN 50091-1, EN 50091-2,GOST, VDE, PEP, EOLI
Form factor > Tower
LED indicators > Battery replacement
Product colour > Beige
Features
Audible alarm modes > Low battery alarm/Overload alarm
Audible alarm(s) > Yes
Efficiency > 98,6 procent
Hold time (max) > 10 Millisecond
Hold time (min) > 6 Millisecond
Input frequency > 50/60 Hz
Input operation voltage (max) > 266 V
Input operation voltage (min) > 180 V
Maximum current > 7 A
Output frequency regulation > 47 - 63 Hz
Output power > 210 Watt
Output power capacity > 0,35 kVA
Power protection features > Overload
Surge energy rating > 310 J
Surge protection > Yes
Surge protection features > Digital Subscriber Line (DSL)/Fax/Modem/Telephone
UPS topology > Standby (Offline)
Logistics data
Harmonized System (HS) code > 85078000
Products per pallet > 48 stuk(s)
Operational conditions
Non-operating altitude > 0 - 15000 m
Operating altitude > 0 - 3000 m
Operating relative humidity (H-H) > 0 - 95 procent
Operating temperature (T-T) > 0 - 40 °C
Storage relative humidity (H-H) > 0 - 95 procent
Storage temperature (T-T) > -15 - 45 °C
Other features
Filtering > Yes
Nominal input voltage > 230 V
Nominal output voltage > 230 V
Package dimensions
Depth (package,cm) > 36,8 cm
Gross Weight (Package, kg) > 7,05 kg
Height (package,cm) > 17,8 cm
Width (package,cm) > 24,1 cm
Packaging data
Bundled software > PowerChute Personal Edition
Cables included > Phone (RJ-11)/USB cable
Quick installation guide > Yes
Software CD > Yes
Warranty card > Yes
Ports & interfaces
AC outlet types > C13 coupler
AC outlets quantity > 4 AC-uitgang(en)
Number of output IEC jumpers > 2
Power plug > C14 coupler
USB port > Yes
Product dimensions
Net Weight (Product, kg) > 6,32 kg
Product Depth > 28,4 cm
Product Height > 16,5 cm
Product Width > 9,1 cm
Technical details
Sustainability certificates > ENERGY STAR/Green Premium/RoHS
Vendor information
Brand Name > APC
Warranty > 1 Ja(a)r(en)
