Artikelcode: 9PX3000IRTM
Netwerk - Noodstroom - UPS
Geschatte levertermijn:
27-09-2026 Contacteer ons
Magazijn: tabr
| Technische details | |
|---|---|
| Duurzaamheidscertificaten: | ENERGY STAR |
| Poorten & interfaces | |
| Stopcontacttypes: | C13 stekker, C19 stekker |
| Stekker: | C20 stekker |
| Aantal AC uitgangen: | 10 AC-uitgang(en) |
| USB-poort: | Ja |
| Aantal USB 2.0-poorten: | 1 |
| Seriële interface: | Ja |
| Soort serieële aansluiting: | RS-232 |
| RS-232 port: | 1 |
| Gewicht en omvang | |
| Breedte: | 440 mm |
| Diepte: | 485 mm |
| Hoogte: | 130 mm |
| Gewicht: | 27,4 kg |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T): | 0 - 40 °C |
| Verpakking | |
| Rekbevestigingspakket: | Ja |
| Beheerskaart inbegrepen: | Nee |
| Meegeleverde software: | Intelligent Power Software suite |
| Accu/Batterij | |
| Batterijtechnologie: | Sealed Lead Acid (VRLA) |
| Typische backup tijd op halve lading: | 9,5 min |
| Hot-swap batterij: | Ja |
| Automatische batterij test: | Ja |
| Overige specificaties | |
| Netspanning, in bedrijf: | 230 V |
| Nominale input voltage: | 230 V |
| Design | |
| Vormfactor: | Rackmontage/toren |
| Kleur van het product: | Zwart |
| Rackcapaciteit: | 3U |
| LED-indicatoren: | Ja |
| Beeldscherm: | LCD |
| Veiligheid: | IEC/EN 62040-1, UL 1778, CSA 22.2 |
| Certificering: | IEC/EN 62040-1, UL 1778, CSA 22.2, IEC/EN 62040 -2, FCC Class B, CISPR22 Class B, CE /CB report (TUV) / cULus / EAC /RCM / KC / Energy Star |
| Kenmerken | |
| UPS-topologie: | Dubbele conversie (online) |
| Output power capacity: | 3 kVA |
| Uitgangsvermogen: | 3000 W |
| Golfvorm: | Zuivere sinus |
| Ingang operation voltage (min): | 176 V |
| Ingang operation voltage (max): | 276 V |
| Frequentie: | 40/70 Hz |
| Uitgang operation voltage (min): | 200 V |
| Uitgang operation voltage (max): | 240 V |
| Output frequentie: | 50/60 Hz |
| Aantal input fases: | 1 |
| Efficientie: | 0,94 procent |
| Power factor: | 1 |
| Geluidsniveau: | 40 dB |
