Artikelcode: 9PX3000IRT2U-L
Netwerk - Noodstroom - UPS
Onbekend levertermijn Contacteer ons
Magazijn: grbr
| Technische details | |
|---|---|
| Duurzaamheidscertificaten: | CE, ENERGY STAR |
| Poorten & interfaces | |
| Stopcontacttypes: | C13 stekker, C19 stekker |
| Stekker: | C20 stekker |
| Aantal AC uitgangen: | 10 AC-uitgang(en) |
| USB-poort: | Ja |
| Aantal USB 2.0-poorten: | 1 |
| USB-poorttype: | USB Type-B |
| Seriële interface: | Ja |
| Soort serieële aansluiting: | RS-232 |
| RS-232 port: | 1 |
| Gewicht en omvang | |
| Breedte: | 440 mm |
| Hoogte: | 86,5 mm |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T): | 0 - 40 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 0 - 96 procent |
| Hoogte, in bedrijf: | 0 - 3000 m |
| Verpakking | |
| Rekbevestigingspakket: | Ja |
| Accu/Batterij | |
| Batterijtechnologie: | Lithium-Ion (Li-Ion) |
| Typische backup tijd op volledige lading: | 10 min |
| Hot-swap batterij: | Ja |
| Automatische batterij test: | Ja |
| Design | |
| Vormfactor: | Rackmontage/toren |
| Kleur van het product: | Zwart, Zilver |
| Rackcapaciteit: | 2U |
| LED-indicatoren: | Ja |
| Beeldscherm: | LCD |
| Veiligheid: | IEC/EN 62040-1, UL 1778, CSA 22.2 |
| Certificering: | IEC/EN 62040-1, UL 1778, CSA 22.2, IEC/EN 62040 -2, FCC Class B, CISPR22 Class B, CE /CB report (TUV) / cULus / EAC /RCM / KC / Energy Star |
| Kenmerken | |
| UPS-topologie: | Dubbele conversie (online) |
| Output power capacity: | 3 kVA |
| Uitgangsvermogen: | 2400 W |
| Golfvorm: | Sinus |
| Ingang operation voltage (min): | 176 V |
| Ingang operation voltage (max): | 276 V |
| Frequentie: | 40/70 Hz |
| Uitgang operation voltage (min): | 200 V |
| Uitgang operation voltage (max): | 240 V |
| Output frequentie: | 50/60 Hz |
| Aantal input fases: | 1 |
| Aantal output fases: | 1 |
| Efficientie: | 94 procent |
| Input vermogensfactor: | 0,99 |
| Output vermogensfactor: | 1 |
| Geluidsniveau: | 40 dB |
| Stroomspanning bescherming: | Batterij-ontlading |
