MerkMSI Form factor moederbordMicro-ATX ChipsetIntel B760 Geheugen slots2 x Max. Geheugen96 GB Geheugen typeDDR5 Wi-FiJa Verkrijgbaar sindsAugustus 2023 DisplayPort versie1.4 Audio ChipRealtek ALC897 Audio-uitgangskanalen7.1 kanalen BIOS typeUEFI AMI Grootte BIOS-geheugen256 Mbit Wi-Fi standaarden802.11a, 802.11g, Wi-Fi 2 (802.11a), Wi-Fi 3 (802.11g), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) Type stroombronATX Component voorPC Geheugen kanaalDubbelkanaals Geheugen slots typeDIMM Non-ECCJa Ondersteunde geheugenkloksnelheid (max)7200 MHz Supported memory clock speeds7200, 7000, 6800, 6600, 6400, 6200, 6000, 5800, 5600, 5400,5200, 5000, 4800 MHz Breedte170 mm Diepte170 mm Aansluiting voor audiopaneel aan voorzijdeJa Aansluiting voor CPU koelerJa SATA-3 6Gbps4 x ATX Power connector (24-pin)Ja RGB LED-aansluitrailJa TPM connectorJa USB 2.0 aansluitingen2 USB 3.0 (3.1 Gen 1)-aansluitingen2 USB 3.1-connectoren (3.1 Gen 2)1 Voorpaneel-connectorJa Netwerk bedraad2500 Mbps EthernetJa Ondersteunde opslagstationinterfacesM.2, SATA III RAID supportJa DisplayPort uit1 x Aantal LAN poorten1 HDMI uit2 x USB 3.2-Gen1 Type A4 x USB 3.2-Gen2 Type A1 x USB 2.0 Poorten2 x BluetoothJa Bluetooth versie5.3 HDMI versie2.1 Moederbord chipset familieIntel Soorten RAID0, 1, 5, 10 Supported processor socketsLGA 1700 Compatibele processorsIntel Celeron, Intel Pentium Gold Max. aantal SMP-processoren1 Socket1700 ProcessorfabrikantIntel Ondersteunt WindowsWindows 10, Windows 11 PCI-E 3.0 x12 x
| Merk | MSI |
| Form factor moederbord | Micro-ATX |
| Chipset | Intel B760 |
| Geheugen slots | 2 x |
| Max. Geheugen | 96 GB |
| Geheugen type | DDR5 |
| Wi-Fi | Ja |
| Verkrijgbaar sinds | Augustus 2023 |
| DisplayPort versie | 1.4 |
| Audio Chip | Realtek ALC897 |
| Audio-uitgangskanalen | 7.1 kanalen |
| BIOS type | UEFI AMI |
| Grootte BIOS-geheugen | 256 Mbit |
| Wi-Fi standaarden | 802.11a, 802.11g, Wi-Fi 2 (802.11a), Wi-Fi 3 (802.11g), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| Type stroombron | ATX |
| Component voor | PC |
| Geheugen kanaal | Dubbelkanaals |
| Geheugen slots type | DIMM |
| Non-ECC | Ja |
| Ondersteunde geheugenkloksnelheid (max) | 7200 MHz |
| Supported memory clock speeds | 7200, 7000, 6800, 6600, 6400, 6200, 6000, 5800, 5600, 5400,5200, 5000, 4800 MHz |
| Breedte | 170 mm |
| Diepte | 170 mm |
| Aansluiting voor audiopaneel aan voorzijde | Ja |
| Aansluiting voor CPU koeler | Ja |
| SATA-3 6Gbps | 4 x |
| ATX Power connector (24-pin) | Ja |
| RGB LED-aansluitrail | Ja |
| TPM connector | Ja |
| USB 2.0 aansluitingen | 2 |
| USB 3.0 (3.1 Gen 1)-aansluitingen | 2 |
| USB 3.1-connectoren (3.1 Gen 2) | 1 |
| Voorpaneel-connector | Ja |
| Netwerk bedraad | 2500 Mbps |
| Ethernet | Ja |
| Ondersteunde opslagstationinterfaces | M.2, SATA III |
| RAID support | Ja |
| DisplayPort uit | 1 x |
| Aantal LAN poorten | 1 |
| HDMI uit | 2 x |
| USB 3.2-Gen1 Type A | 4 x |
| USB 3.2-Gen2 Type A | 1 x |
| USB 2.0 Poorten | 2 x |
| Bluetooth | Ja |
| Bluetooth versie | 5.3 |
| HDMI versie | 2.1 |
| Moederbord chipset familie | Intel |
| Soorten RAID | 0, 1, 5, 10 |
| Supported processor sockets | LGA 1700 |
| Compatibele processors | Intel Celeron, Intel Pentium Gold |
| Max. aantal SMP-processoren | 1 |
| Socket | 1700 |
| Processorfabrikant | Intel |
| Ondersteunt Windows | Windows 10, Windows 11 |
| PCI-E 3.0 x1 | 2 x |
