| Processor | |||
|---|---|---|---|
| Processorfabrikant: | AMD | Processor socket: | Socket AM4 |
| Compatibele processors: | AMD Ryzen 3 3rd Gen, 3rd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen 7, 3rd Generation AMD Ryzen 9 | Max. aantal SMP-processoren: | 1 |
| Geheugen | |||
| Ondersteunde geheugen types: | DDR4-SDRAM | Aantal geheugenslots: | 4 |
| Maximum intern geheugen: | 128 GB | Geheugen slots type: | DIMM |
| Supported memory clock speeds: | 2133,2400,2666,2800,3000,3200,3466,3600,3866,4000,4133,4400,4600 MHz | ||
| Gewicht en omvang | |||
| Breedte: | 305 mm | Diepte: | 244 mm |
| Netwerk | |||
| Wifi: | Ja | Ethernet LAN: | Ja |
| Ethernet interface type: | 2.5 Gigabit Ethernet | LAN controller: | Intel I225-V |
| Wake-on-LAN: | Ja | Wifi-standaard: | Wi-Fi 6 (802.11ax) |
| Wi-Fi-standaarden: | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax) | Bluetooth: | Ja |
| Bluetooth-versie: | 5.2 | ||
| Interne aansluitingen | |||
| USB 2.0 aansluitingen: | 2 | USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen: | 1 |
| USB 3.2-connectoren (3.1 Gen 2): | 1 | Aantal SATA III connectors: | 6 |
| Aansluitingen voor EATX voedingen: | 1 | Aansluiting voor CPU koeler: | Ja |
| Aansluitingen voor behuizingsventilatoren: | 3 | Peripheral (Molex) power connectors (4-pin): | 1 |
| EPS power connector (8-pin): | Ja | Thunderbolt-headers: | 1 |
| 12V vermogen-connector: | Ja | RGB LED-aansluitrail: | Ja |
| Aansluitingen achterzijde | |||
| Aantal USB 2.0-poorten: | 2 | Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A: | 4 |
| Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A: | 1 | Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C: | 1 |
| Aantal Ethernet LAN (RJ-45)-poorten: | 1 | Aantal HDMI-poorten: | 1 |
| HDMI versie: | 2.1 | Aantal DisplayPorts: | 1 |
| DisplayPort versie: | 1.2 | Hoofdtelefoonuitgangen: | 1 |
| Microfoon, line-in ingang: | Ja | S/PDIF-uitgang: | Ja |
| Opslag-controllers | |||
| Ondersteunde opslagstationinterfaces: | M.2,SATA III | Ondersteunde types opslag-drives: | HDD & SSD |
| Maximum aantal HDD's per behuizing: | 6 | Soorten RAID: | 0,1,10 |
| Inhoud van de verpakking | |||
| Meegeleverde kabels: | SATA | Meegeleverde drivers: | Ja |
| Uitbreidingsmodules | |||
| PCI Express x1 (Gen 3.x) slots: | 3 | PCI Express x16 (Gen 3.x) slots: | 1 |
| PCI Express x16 (Gen 4.x) sleuven: | 1 | Aantal M.2 (M) slots: | 2 |
| BIOS | |||
| BIOS type: | UEFI AMI | Grootte BIOS-geheugen: | 256 Mbit |
| Grafisch | |||
| Ondersteuning voor parallel processing: | Niet ondersteund | ||
| Kenmerken | |||
| Component voor: | PC | Moederbord form factor: | ATX |
| Moederbord chipset familie: | AMD | Chipset moederbord: | AMD B550 |
| Audio-uitgangskanalen: | 7.1 kanalen | Type koeling: | Actief |
| Type stroombron: | ATX | Ondersteunt Windows: | Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64 |
