| Processor | |
|---|---|
| Processorfamilie: | Intel Celeron |
| Processorfabrikant: | Intel |
| Processormodel: | N3050 |
| Frequentie van processor: | 1,6 GHz |
| Maximale turbofrequentie van processor: | 2,16 GHz |
| Aantal processorkernen: | 2 |
| Processor aantal threads: | 2 |
| Processor cache: | 2 MB |
| CPU configuratie (max): | 1 |
| ECC ondersteund door processor: | Nee |
| Geïntegreerde 4G WiMAX: | Nee |
| PCI Express slots versie: | 2.0 |
| Processor cache type: | L2 |
| Codenaam processor: | Braswell |
| Processor lithografie: | 14 nm |
| Processor operating modes: | 64-bit |
| Verpakkingsgrootte processor: | 25 x 27 mm |
| Processorserie: | Intel Celeron N3000 series |
| Processor socket: | BGA 1170 |
| Scenario Design Power (SDP): | 4 W |
| Stepping: | C0 |
| Systeembus: | 5 GT/s |
| Tjunction: | 90 °C |
| Thermal Design Power (TDP): | 6 W |
| On-board graphics adapter model: | Intel HD Graphics |
| Maximaal intern geheugen ondersteund door processor: | 8 GB |
| Conflictvrije processor: | Ja |
| Geheugen | |
| Intern geheugen: | 2 GB |
| Intern geheugentype: | DDR3L |
| Kloksnelheid geheugen: | 1600 MHz |
| Poorten & interfaces | |
| Aantal Ethernet LAN (RJ-45)-poorten: | 1 |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A: | 3 |
| Aantal HDMI-poorten: | 1 |
| Gewicht en omvang | |
| Breedte: | 164 mm |
| Diepte: | 218 mm |
| Hoogte: | 165 mm |
| Gewicht: | 1,6 kg |
| Energie | |
| Stroomverbruik (typisch): | 24,5 W |
| Slaapstand: | 0,69 W |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T): | 5 - 35 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 5 - 95 procent |
| Netwerk | |
| Ethernet LAN: | Ja |
| Ethernet LAN, data-overdrachtsnelheden: | 10,100,1000 Mbit/s |
| Wifi: | Nee |
| DHCP client: | Ja |
| Jumbo Frames ondersteuning: | Ja |
| iSCSI support: | Ja |
| Wake-on-LAN: | Ja |
| Ondersteunde netwerkprotocollen: | CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI, HTTP, HTTPS, Proxy, SNMP, Syslog |
| Opslagmedia | |
| Opslagdrives geïnstalleerd: | Nee |
| Aantal storage drives ondersteund: | 4 |
| Geïnstalleerde opslag-drive: | Nee |
| Ondersteunde types opslag-drives: | HDD |
| Opslag schijf-interface: | SATA II, SATA III |
| RAID support: | Ja |
| Opslag schijfgrootte: | 3.5" |
| Maximaal ondersteunde opslagcapaciteit: | 32 TB |
| Soorten RAID: | 0, 1, 5, 6, 10, JBOD |
| Hot-swap drive bays: | Ja |
| Ondersteunde bestandsystemen: | FAT32, HPFS, NTFS, ext3, ext4 |
| Certificaten | |
| Certificering: | FCC, CE, VCCI, BSMI, C-TICK |
| Software | |
| Inclusief besturingssysteem: | ADM |
| Operating systeem versie: | 2,6 |
| Ondersteunt Windows: | Ja |
| Ondersteunt Linux: | Ja |
| Ondersteunt Mac-besturingssysteem: | Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Ondersteunde server operating systems: | Windows Server 2003, Windows Server 2008, Windows Server 2012 |
| Overige specificaties | |
| ARK ID processor: | 87257 |
| Design | |
| Type koeling: | Actief |
| Kleur van het product: | Zwart |
| Aantal ventilatoren: | 1 ventilator(en) |
| Ventilator diameter: | 12 cm |
| Grafisch | |
| Basisfrequentie ingebouwde grafische adapter: | 320 MHz |
| On-board grafische adapter burst frequentie: | 600 MHz |
| Maximaal geheugen ingebouwde grafische adapter: | 8 GB |
| Aantal displays ondersteund (door on-board grafische adapter): | 3 |
| Processor speciale functies | |
| Ingebouwde opties beschikbaar: | Nee |
| Enhanced Intel SpeedStep Technology: | Ja |
| Execute Disable Bit: | Ja |
| Idle States: | Ja |
| Intel 64: | Ja |
| Intel Clear Video-technologie: | Ja |
| Intel Enhanced Halt State: | Ja |
| Versie Intel Identity Protection Technology: | 1,00 |
| Intel Rapid Storage Technology: | Nee |
| Intel Veilig opstarten: | Ja |
| Versie Intel Secure Boot Technology: | 1,00 |
| Versie Intel Secure Key Technology: | 1,00 |
| Intel Small Business Advantage (SBA)-versie: | 0,00 |
| Intel Smart Connect Technology: | Nee |
| Versie Intel Smart Connect Technology: | 0,00 |
| Versie Intel Smart Response Technology: | 0,00 |
| Intel Stable Image Platform Program (SIPP): | Nee |
| Versie Intel Stable Image Platform Program (SIPP): | 0,00 |
| Intel Trusted Execution Technology: | Nee |
| Intel Virtualization Technology (VT-x): | Ja |
| Intel Virtualization Technology for Directed I/O (VT-d): | Nee |
| Intel VT-x with Extended Page Tables (EPT): | Ja |
| Intel AES New Instructions (Intel AES-NI): | Ja |
| Intel Anti-Theft Technology (Intel AT): | Nee |
| Intel Clear Video HD Technology (Intel CVT HD): | Ja |
| Intel Clear Video Technology for Mobile Internet Devices (Intel CVT for MID): | Ja |
| Intel High Definition Audio (Intel HD Audio): | Ja |
| Intel Hyper Threading Technology (Intel HT Technology): | Nee |
| Intel Identity Protection Technology (Intel IPT): | Ja |
| Intel Insider: | Nee |
| Intel InTru 3D Technology: | Nee |
| Intel OS Guard: | Nee |
| Intel Quick Sync Video Technology: | Ja |
| Intel Secure Key: | Ja |
| Intel Small Business Advantage (Intel SBA): | Nee |
| Intel Smart Response Technology: | Nee |
| Intel Turbo Boost Technology: | Nee |
| Intel Wireless Display (Intel WiDi): | Ja |
| Maximaal aantal PCI Express-lijnen: | 4 |
| Aantal verwerkingseenheden: | 12 |
| Thermal Monitoring Technologies: | Ja |
| UART: | Ja |
| Geheugenkanalen ondersteund door processor: | Dual |
| Geheugentypen ondersteund door processor: | DDR3L-SDRAM |
| Prestatie | |
| Soort: | NAS |
| Apparaatklasse: | Home & Home Office |
| Backup-functie: | Ja |
| Back-up-eigenschappen: | Cloud |
| Ondersteunt meerdere talen: | Ja |
| Geluidsniveau (buiten gebruik): | 19,7 dB |
| Ondersteunde beveiligingsalgoritmen: | HTTPS, SSH, SSL/TLS |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS): | 84714100 |
