Antenna
Antenna design > External
Antennas quantity > 6
Design
Indication light > Yes
LED indicators > LAN, Power, WAN, WLAN
On/off switch > Yes
Product colour > Black
Product type > Tabletop router
Features
Built-in processor > Yes
Flash memory > 256 MB
Internal memory > 512 MB
Processor cores > 4
Processor frequency > 2000 MHz
Management features
Quality of Service (QoS) support > Yes
Reset button > Yes
Wake-on-LAN ready > Yes
WPS push button > Yes
Network
Built-in FTP server > Yes
Dynamic DNS (DDNS) > Yes
Ethernet LAN > Yes
Ethernet LAN data rates > 1000, 2500
Ethernet LAN interface type > Gigabit Ethernet
Media server > Yes
Networking standards > IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Number of guest networks (2.4 GHz) > 3
Number of guest networks (5 GHz) > 3
Port forwarding > Yes
Support Samba (storage) > Yes
VPN server > VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard
VPN support > VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion
Package dimensions
Gross Weight (Package, kg) > 1,17 kg
Packaging content
AC adapter included > Yes
Cables included > LAN (RJ-45)
Quick start guide > Yes
Warranty card > Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports > 6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity > 1
USB port > Yes
Power
AC input frequency > 50/60 Hz
AC input voltage > 100 - 240 V
Output current > 2,5 A
Output voltage > 12 V
Power source type > AC
Product dimensions
Net Weight (Product, kg) > 0,9 kg
Protocols
DHCP server > Yes
Security
DMZ support > Yes
Firewall > Yes
Firewall security > Maximum Firewall Keyword Filter : 64 • Maximum Firewall Network Service Filter : 32 • Maximum Firewall URL Filter : 64
MAC address filtering > Yes
NAT functionality > NAT Passthrough : PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE relay
Network address translation (NAT) > Yes
Parental control > Yes
Security algorithms > SSH, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3-PSK, WPS
System event log > Yes
Vendor information
Brand Name > Asus
Warranty > 1 Ja(a)r(en)
WAN connection
3G/4G USB modem compatibility > Yes
Ethernet WAN > Yes
SIM card slot > No
Wireless LAN features
Modulation > 1024-QAM
Top Wi-Fi standard > Wi-Fi 6 (802.11ax)
Wi-Fi band > Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards > 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
WLAN data transfer rate (first band) > 1148 Mbit/s
WLAN data transfer rate (max) > 6000 Mbit/s
WLAN data transfer rate (second band) > 4804 Mbit/s
