Antenna
Antenna design > External
Antennas quantity > 3
Design
Housing material > Acrylonitrile butadiene styrene (ABS)
Indication light > Yes
LED indicators > ADSL, DSL, LAN, Power, WLAN
On/off switch > Yes
Product colour > Black
Product type > Tabletop router
DSL features
ADSL > Yes
ADSL2 > Yes
ADSL2+ > Yes
VDSL > Yes
VDSL2 > Yes
Features
Certification > CE
Firmware upgradeable > Yes
Plug and Play > Yes
Management features
Quality of Service (QoS) support > Yes
Reset button > Yes
Web-based management > Yes
Web-based setup wizard > Yes
WPS push button > Yes
Mobile network
3G > No
4G > No
Mobile network generation > 4G
Network
Cabling technology > 10/100/1000Base-T(X)
Ethernet LAN > Yes
Ethernet LAN data rates > 10, 100, 1000
Ethernet LAN interface type > Gigabit Ethernet
Networking standards > IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Port forwarding > Yes
VPN Passthrough > Yes
VPN support > IPSec Pass-Through PPTP Pass-Through L2TP Pass-Through PPTP server OpenVPN server PPTP client L2TP client OpenVPN client
Operational conditions
Operating relative humidity (H-H) > 50 - 90 procent
Operating temperature (T-T) > 0 - 40 °C
Storage relative humidity (H-H) > 20 - 90 procent
Storage temperature (T-T) > 0 - 70 °C
Package dimensions
Gross Weight (Package, kg) > 0,45 kg
Packaging content
AC adapter included > Yes
Cables included > DSL, LAN (RJ-45), Phone (RJ-11)
Quick start guide > Yes
Packaging data
Wi-Fi configuration card > Yes
Ports & interfaces
DC-in jack > Yes
Ethernet LAN (RJ-45) ports > 2
Memory card slot(s) > No
RJ-11 ports quantity > 1
USB port > No
Power
AC input frequency > 50 - 60 Hz
AC input voltage > 100 - 240 V
Output current > 1 A
Output voltage > 12 V
Power source type > AC, DC
Product dimensions
Net Weight (Product, kg) > 0,44 kg
Product Depth > 17,5 cm
Product Height > 20 cm
Product Width > 20,7 cm
Protocols
DHCP client > Yes
DHCP server > Yes
Management protocols > IGMP v1/v2/v3
Supported network protocols > IPv4, IPv6
Universal Plug and Play (UPnP) > Yes
Security
DMZ support > Yes
Filtering > Yes
Firewall > Yes
Firewall security > Parental control
Guest access > Yes
IP address filtering > Yes
Network address translation (NAT) > Yes
Port-based Network Access Control (PNAC) > Yes
Security algorithms > 64-bit WEP, 128-bit WEP, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPS
System event log > Yes
URL filtering > Yes
System requirements
Linux operating systems supported > Yes
Mac compatibility > Yes
Mac operating systems supported > Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Windows operating systems supported > Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Vendor information
Brand Name > Asus
Warranty > 1 Ja(a)r(en)
WAN connection
3G/4G USB modem compatibility > No
DSL WAN > Yes
Ethernet WAN > Yes
SIM card slot > No
Wireless LAN features
Top Wi-Fi standard > Wi-Fi 5 (802.11ac)
Wi-Fi band > Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards > 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rate (first band) > 300 Mbit/s
WLAN data transfer rate (max) > 433 Mbit/s
WLAN data transfer rate (second band) > 433 Mbit/s
