Artikelcode: 7D1XA02JEA
Computers - Servers - Tower
Onbekend levertermijn Contacteer ons
Magazijn: tabr
| Processor | |
|---|---|
| Processorfamilie: | Intel Xeon D |
| Processorfabrikant: | Intel |
| Processormodel: | D-2143IT |
| Frequentie van processor: | 2,2 GHz |
| Maximale turbofrequentie van processor: | 3 GHz |
| Aantal processorkernen: | 8 |
| Processor cache: | 11 MB |
| Aantal geïnstalleerde processoren: | 1 |
| Thermal Design Power (TDP): | 65 W |
| Processor socket: | BGA 2518 |
| Processor lithografie: | 14 nm |
| Processor aantal threads: | 16 |
| Processor operating modes: | 64-bit |
| Stepping: | M1 |
| Bus type: | UPI |
| Codenaam processor: | Skylake |
| Maximaal intern geheugen ondersteund door processor: | 512 GB |
| Geheugentypen ondersteund door processor: | DDR4-SDRAM |
| Klokgeheugen-snelheden ondersteund door processor: | 2133 MHz |
| Execute Disable Bit: | Ja |
| Idle States: | Ja |
| Thermal Monitoring Technologies: | Ja |
| Maximaal aantal PCI Express-lijnen: | 32 |
| Ondersteunde instructie sets: | AVX 2.0 |
| Processorcode: | SR3ZU |
| Schaalbaarheid: | 1S |
| Ingebouwde opties beschikbaar: | Ja |
| Conflictvrije processor: | Ja |
| Geheugen | |
| Intern geheugen: | 32 GB |
| Intern geheugentype: | DDR4-SDRAM |
| Maximum intern geheugen: | 256 GB |
| Geheugenslots: | 4 |
| ECC: | Ja |
| Kloksnelheid geheugen: | 2666 MHz |
| Geheugenlayout: | 1 x 32 GB |
| Poorten & interfaces | |
| Aantal USB 2.0-poorten: | 2 |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A: | 2 |
| VGA (D-Sub)poort(en): | 1 |
| Seriële poort(en): | 1 |
| Gewicht en omvang | |
| Breedte: | 209 mm |
| Diepte: | 376 mm |
| Hoogte: | 43 mm |
| Gewicht: | 3,75 kg |
| Energie | |
| Redundante voeding: | Ja |
| Aantal geïnstalleerde redundante voedingen: | 1 |
| Netwerk | |
| Wifi: | Ja |
| Wi-Fi-standaarden: | Wi-Fi 5 (802.11ac) |
| Wake-on-LAN: | Ja |
| Ethernet LAN: | Ja |
| Bekabelingstechnologie: | 10/100/1000Base-T(X) |
| Ethernet interface type: | 10 Gigabit Ethernet, Gigabit Ethernet |
| Opslagmedia | |
| Maximale opslagcapaciteit: | 15,68 TB |
| RAID support: | Ja |
| Soort optische drive: | Nee |
| SSD interfaces: | M.2 |
| Aantal ondersteunde SSD's: | 4 |
| Soorten RAID: | 0, 1, 5, 10 |
| Software | |
| Compatibele besturingssystemen: | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi. Ubuntu Server certification. |
| Uitbreidingsmodules | |
| PCI Express slots versie: | 3.0 |
| Design | |
| Type behuizing: | Rack (1U) |
| Kleur van het product: | Zwart |
| Grafisch | |
| Ingebouwde grafische adapter: | Ja |
| On-board graphics adapter model: | Matrox G200 |
| Processor speciale functies | |
| CPU configuratie (max): | 1 |
| Enhanced Intel SpeedStep Technology: | Ja |
| Intel Virtualization Technology for Directed I/O (VT-d): | Ja |
| Intel Hyper Threading Technology (Intel HT Technology): | Ja |
| Intel Turbo Boost Technology: | 2.0 |
| Intel AES New Instructions (Intel AES-NI): | Ja |
| Intel Trusted Execution Technology: | Ja |
| Intel Enhanced Halt State: | Ja |
| Intel VT-x with Extended Page Tables (EPT): | Ja |
| Intel Secure Key: | Ja |
| Intel TSX-NI: | Ja |
| Intel OS Guard: | Ja |
| Intel Software Guard Extensions (Intel SGX): | Nee |
| Intel 64: | Ja |
| Versie Intel Secure Key Technology: | 1,00 |
| Intel Virtualization Technology (VT-x): | Ja |
| Versie Intel TSX-NI: | 1,00 |
| Intel QuickAssist-technologie: | Nee |
| ARK ID processor: | 136431 |
| Prestatie | |
| Prestatiebeheer: | XClarity Enterprise |
| Trusted Platform Module (TPM): | Ja |
| Trusted Platform Module (TPM) version: | 2.0 |
