Design
Cooling type > Active
Fan diameter > 12 cm
Illumination > No
Number of fans > 1 ventilator(en)
On/off switch > Yes
Product colour > Black
Package dimensions
Gross Weight (Package, kg) > 0,65 kg
Performance
80 PLUS certification > 80 PLUS Bronze
Power supply unit (PSU) form factor > ATX
Purpose > PC
Ports & interfaces
ATX Power connector (24-pin) > Yes
EPS power connector (4+4 pin) > Yes
Floppy drive power connector > 1
Motherboard power connector > 24-pin ATX
Number of SATA power connectors > 5
PCI Express power connectors (16-pin) > 1
PCI Express power connectors (6+2 pin) > 2
Peripheral (Molex) power connectors (4-pin) > 2
Power
AC input frequency > 50/60 Hz
AC input voltage > 100 - 240 V
Combined power (-12V) > 3,6 Watt
Combined power (+12V) > 750 Watt
Combined power (+3.3V) > 120 Watt
Combined power (+5V) > 120 Watt
Combined power (+5Vsb) > 12,5 Watt
Efficiency > 85 procent
Max output current (-12V) > 0,3 A
Max output current (+12V) > 62,5 A
Max output current (+3.3V) > 20 A
Max output current (+5V) > 20 A
Max output current (+5Vsb) > 2,5 A
Maximum input current (@110V) > 10 A
Maximum input current (@220V) > 5 A
Power Factor Correction (PFC) type > Active
Power protection features > Over current, Over power, Over voltage, Short circuit
Total power > 750 Watt
Product dimensions
Net Weight (Product, kg) > 0,5 kg
Vendor information
Brand Name > MSI
Warranty > 1 Ja(a)r(en)
